LG 55UH5F-H

Descripción

PANEL

Screen Size 55″

Panel Technology IPS

Native Resolution 3,840 x 2,160 (UHD)

Brightness (Typ.) 500

Contrast Ratio 1,100:1

Dynamic CR 1,000,000 : 1 *The luminosity ratio of Full Black / Full White color on video input condition.

Color gamut BT709 95%

Viewing Angle (H x V) 178 x 178

Color Depth 1.07 Billion Colors (10 bit)

Response Time 8 ms (G to G)

Surface Treatment (Haze) Haze 28%

Operation Hours (Hours / Day) 24 / 7

Portrait / Landscape Yes / Yes

CONNECTIVITY

Input HDMI (2, HDCP 2.2/1.4), HDMI (1, HDCP 1.4), DP (1, HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio, USB 2.0 Type A

Output DP, Audio

External Control RS232C (4 Pin Phone Jack) In / Out, RJ45(LAN) In, IR In

MECHANICAL SPECIFICATION

Bezel Color Black

Bezel Width 9.9mm(T/R/L), 14.4mm(B)

Weight (Head) 19.0 kg

Monitor Dimension (W × H × D) 1,234.4mm x 720.9mm x 39.9mm

Monitor Dimensions with Stand (W × H × D) 1,234.4 × 770.7 × 290.0 mm

Handle No

VESA™ Standard Mount Interface 300 x 300 mm

SPECIAL FEATURE

Tilt (Facedown) Yes (Max. 30º) *In conditions within 30ºC temperature, 50% humidity

IP Rating IP5X

ENVIRONMENT CONDITIONS

Operation Temperature 0°C to 40°C

Operation Humidity 10% to 80%

POWER

Power Supply AC 100-240V~, 50/60Hz

Power Type Built-In Power

POWER CONSUMPTION

/ Max. 105W / 145W

BTU (British Thermal Unit) 358 BTU/Hr (Typ.), 495 BTU/Hr (Max.)

SOUND

Speaker Yes
